Key Features -
Optimized rider ergonomics with a narrow tank, flatter seat and slimmer radiator shrouds offering greater freedom of movement
-
Advanced liquid-cooled YPVS-equipped 249cc two-stroke engine is lightweight, compact and fun, with a wide, hard-hitting powerband
-
Straight intake design improves feeling of power in the low rpm range
-
Advanced Hitachi Astemo® Keihin PWK38S carburetor with power jet and throttle position sensor provides extra-crisp throttle response
-
High performance brake setup features large front pistons, rigid caliper and rotors with maximized pad contact area for exceptional stopping power and feel.
-
Fully adjustable KYB® fork features the Speed-Sensitive System for precise handling and superb shock absorption
-
Fully adjustable KYB® rear shock features reduced-friction Kashima Coat™ internals
-
Race-proven, highly developed forged aluminum semi-double cradle frame
-
Removable aluminum rear subframe constructed of square-section tubing for reduced weight
-
Finely tuned lightweight chassis and advanced suspension endow the YZ250 with class-leading handling
- Compact, liquid-cooled, 249 cc, piston-reed-valve-inducted, 2-stroke engine
- Smooth shifting, 6-speed, close ratio transmission
- Keihin PWK38S carb with 4-petal carbon fiber reeds
- Yamaha's patented YPVS exhaust power valve system
- Lightweight, aluminum, semi-double-cradle frame with detachable rear subframe
- Fully adjustable KYB suspension
- 270 mm front & 245 mm rear disc brakes
- Adjustable aluminum handlebar & titanium foot pegs
- Aggressive, modern styling
|
ENGINE -
Lightweight, compact, liquid-cooled, 249cc, piston-reed-valve-inducted, 2-stroke.
- super crisp, instant 'right now' engine power (when in the 'power band')
- easy & economical to maintain, service & rebuild
-
Lightweight, flat top forged aluminum piston.
- excellent durability
- light weight means fast engine response
-
Liner-less, ceramic composite cylinder bore with ceramic coating sprayed directly on the aluminum block.
- excellent heat dissipation
- reduced weight (no heavy iron liner)
- reduced friction
- extended cylinder life
-
Lightweight, ball bearing style crank.
- lightweight design for fast throttle response
- friction reducing crank seals
-
YPVS power valve system features a total of three slides (one main and two auxiliary slides).
- YPVS system varies the exhaust port height & timing based on engine rpm
- provides the benefits of both solid, low rpm power delivery & strong top-end punch
-
Keihin PWK38S carburetor with power jet and throttle position sensor (TPS).
- precise fuel - air mixing
- extra-crisp throttle response throughout the powerband
-
Special-design, 4-petal, carbon fiber reeds.
- excellent throttle response & engine performance across the entire RPM range
-
Smooth-shifting, 5-speed, close-ratio transmission.
- ratios are matched to engine output for maximum performance
- optimal hook-up for outstanding acceleration & corner-exiting power
- transmission features 'involute splines' for smooth, positive shifting even under power
-
Heavy-duty, multi-plate clutch.
- quick-access, outer clutch cover allows for fast, easy clutch maintenance
-
CD (capacitor discharge) ignition system.
- delivers a precise spark for fast, sure starts
- ensures optimal timing at all rpms for fast, strong response.
-
High capacity, washable, dual-stage, foam air filter.
- excellent filtering qualities
- reduces maintenance costs... foam filter is re-useable
-
Large-capacity, dual radiators feature 10-row cores.
- maximum cooling efficiency
-
Lightweight exhaust system.
- computer designed expansion chamber provides maximum engine performance
- lightweight, aluminum silencer is re-buildable for optimum performance & reduced noise levels
-
Works-style clutch lever & race-spec 'barrel adjuster.'
- light, easy lever pull
- for on-the-fly clutch adjustments
|
CHASSIS/SUSPENSION -
Lightweight, aluminum, semi-double-cradle frame.
- combines with compact engine to provide an awesome power to weight ratio
- obvious benefit of an aluminum frame is a significant weight reduction
- Yamaha maintains the semi-double cradle design because it offers an excellent 'rigidity balance' between lateral & torsional rigidity while offering controlled flex in the longitudinal plane
- result is a light aluminum frame, which provides excellent handling, good ride quality, excellent stability & responsive cornering performance
-
Removable rear subframe.
- constructed of square-section, lightweight aluminum
- detachable design allows easy access when servicing rear suspension components
- reduces costs in the event of a loop out
-
Lightweight, tapered design aluminum swingarm.
- produced by 'hydro forming', a forming method that uses high pressure water to form shapes
- excellent rear wheel traction & control
- lightweight design
-
Cast aluminum upper and forged lower triple clamps.
- strong yet lightweight
- fast, agile handling
-
Adjustable handlebar mounts.
- allow handlebar to be moved 10mm rearward if desired
-
'Speed Sensitive System' 48mm, adjustable, inverted, 'twin chamber' KYB fork. Front wheel travel is 300mm (11.8').
- twin chamber design means the damper unit is in a separate structure which prevents aerated fork oil from entering the inner damper assembly & degrading its damping abilities
- the inner damper is pressurized, it also eliminates bubbles forming in the oil
- 'Speed Sensitive' design means the damping force is controlled by piston speed, not position in the fork
- low friction fork seals provide reduced stiction for a smoother stroke
- fork adjustments include: 20-way compression damping & 20-way rebound damping
- optional fork springs are available through Genuine Yamaha parts
-
Fork also features a Transfer Control Valve (TCV).
- TCV enhances damping from mid to full stroke & improves bottoming characteristics
- TCV offers more precise control throughout the full suspension stroke
- TCV is located on the upside of the spring & its function is controlled by piston speed, not piston position, hence the term 'Speed Sensitive System fork'
-
Large 'wrap-around' plastic fork protectors.
- provide excellent protection from dirt, mud & stone chips
- 'self-supporting' design reduces friction for smoother stroke
-
Monocross link rear suspension features a fully adjustable, Kayaba, piggyback shock which provides 315mm (12.4') of wheel travel.
- features separate adjusters for high- and low-speed compression damping
- adjustments include: spring preload, 20-way rebound damping, 20-way low-speed compression damping & 2 turns of high speed compression damping
- damper rod is 18 mm in diameter
- Kashima coating (friction reducer) is used in the shock body & sub tank to reduce friction & improve suspension performance
- piggyback shock utilizes a full rebound oil lock system for excellent suspension function & great ride quality
-
270 mm floating front 'wave-style' disc brake with Nissin twin piston caliper.
- 'wave' style rotor (disc) reduces weight, improves cooling (more surface area) & improves styling
- braking performance is excellent with great feel & control
-
'Shorty' front brake lever is adjustable for various hand sizes.
-
245 mm rear 'wave-style' disc brake with single piston caliper.
- integrated master cylinder (fluid reservoir is integrated into the top of the master cylinder)
- 'wave' style rotor (disc) reduces weight, improves cooling (more surface area) & improves styling
- strong stopping power with excellent feel & control
-
Rugged, plastic rear caliper & lower rear disc protectors / guards.
-
Lightweight, Sun Star rear sprocket.
- increases the contact area between the sprocket & chain rollers
- reduces the load on the chain & increases service life of chain & sprocket
-
Lightweight, D.I.D. 21' front and 19' rear rims & premium Dunlop tires.
- provide excellent durability
- reduces unsprung weight for optimal suspension performance & handling
-
'Flat-design' seat features multi density foam.
- provides good initial softness / comfort and then increases the firmness as more pressure is applied
- 'pebble' finish on the top and side surfaces provides excellent rider grip & durability
-
Seat, handlebar & fuel tank ergonomics provide excellent freedom of movement for the rider.
|
DETAILS -
Iconic Heritage YZ Styling
- Class-leading four-stroke performance wrapped in iconic heritage YZ style, the YZ250 50th Anniversary Edition draws its inspiration from 1990s-era Yamaha two-stroke motocrossers to honor 50 years of Yamaha off-road innovation.
- Slim design, modern aggressive bodywork allows easy rider movements
- Lightweight YZ250F/450F based wide footpegs provide excellent grip & ground clearance
- Rugged chain guide helps prevent the chain from de-railing and also helps to protect the rear sprocket.
- Serrated rear brake lever and folding shift lever tip
- Stainless steel, inner clutch cable provides excellent strength, smooth action and long life
- Heavy-duty chain
- E10 friendly fuel system components
|
CLASS LEADING KYB® SUSPENSION
EXHILIRATING 2 STROKE POWER
Confidence-Inspiring Ergonomics
